Displaying BGP4+ information
9
Displaying BGP4+ neighbor route-attribute entries
The route-attribute entries table lists sets of BGP4+ attributes stored in the Virtual ADX device’s
memory. Each set of attributes is unique and can be associated with one or more routes. In fact,
the Virtual ADX typically has fewer route attribute entries than routes.
For example, to display the route-attribute entries table for a BGP4+ neighbor
2001:db8:2000:4::110, enter the following command.
Syntax: show ipv6 bgp neighbor ipv6-address attribute-entries
The ipv6-address parameter displays the route attribute entries for a specified neighbor. You must
specify this address in hexadecimal using 16-bit values between colons as documented in RFC
2373.
Next Hop
For information about this field, refer to
Learned from Peer
The IPv6 address of the neighbor from which this route is
learned. “Local Router” indicates that the Virtual ADX device
itself learned the route.
LOCAL_PREF
For information about this field, refer to
MED
The value of the advertised route’s MED attribute. If the route
does not have a metric, this field is blank.
Origin
The source of the route information. The origin can be one of the
following:
•
EGP – The routes with this set of attributes came to BGP4+
through EGP.
•
IGP – The routes with this set of attributes came to BGP4+
through IGP.
•
INCOMPLETE – The routes came from an origin other than
one of the above. For example, they may have been
redistributed from OSPFv3.
When BGP4+ compares multiple routes to a destination to select
the best route, IGP is preferred over EGP and both are preferred
over INCOMPLETE.
Weight
For information about this field, refer to
AS-PATH
The AS-path information for the route.
Adj RIB out count
The number of routes in the Virtual ADX device’s current BGP4+
Routing Information Base (Adj-RIB-Out) for a specified neighbor.
Admin distance
The administrative distance of the route.
TABLE 11
Detailed route information advertised to a BGP4+ neighbor (Continued)
This field...
Displays...
Virtual ADX# show ipv6 bgp neighbor 2001:db8:2000:4::110 attribute-entries
Total number of BGP Attribute Entries: 1
1 Next Hop :2001:db8:2000:4::106 Metric :1 Origin:IN
Originator:0.0.0.0
Aggregator:AS Number :0 Router-ID:0.0.0.0 Atomic:None
Local Pref:100 Communities:Internet
AS Path :65001
Address: 0x26579354 Hash:332 (0x0301fcd4) Reference Counts: 2:0:0
