Watlow EZ-ZONE ® PM PID Controller • 84 • Chapter 9 Features
Changing PM PID Model Number to PM Express
EZ-ZONE PM firmware revisions of 13 and above allow the user to switch between a PM PID control to a PM
Express. Switching to a PM Express eliminates the complexity of the PM PID control by allowing the user to
operate with a simplified menu structure.
Note:
When switching from an integrated control to an Express version, optional PM hardware (even though in-
stalled) and firmware features not available in a PM Express will no longer work. To see exactly what is
impacted by this change, compare the chart below to the ordering information page in this document.
Controller PM _ _ _ _ _ - _ _ _ _ B _ _
EZ-ZONE® PID Controller Changes to PM Express
Red-green 7-segment displays
Package Size
No Change
Primary Function
C PID Controller with Universal Input
R
B
J PID Controller with Universal Input
N
E
S Custom Firmware
Power Supply
1 100 to 240V Å (ac)
2 Changes to 1
3 15 to 36VÎ (dc) and 24VÅ (ac)
4 Changes to 3
Output 1 and 2 Hardware Options
Output 1 Output 2
CA Switched dc/open collector None
CH Switched dc/open collector NO-ARC 15 A power control
CC Switched dc/open collector Switched dc
CJ Switched dc/open collector Mechanical relay 5 A, form A
CK Switched dc/open collector Solid-state relay 0.5 A, form A
EA Mechanical relay 5 A, form C None
EH Mechanical relay 5 A, form C NO-ARC 15 A power control
EC Mechanical relay 5 A, form C Switched dc
EJ Mechanical relay 5 A, form C Mechanical relay 5 A, form A
EK Mechanical relay 5 A, form C Solid-state relay 0.5 A, form A
FA Universal process None
FC Universal process Switched dc (cannot use variable time base)
FJ Universal process Mechanical relay 5 A, form A (cannot use variable time base)
FK Universal process Solid-state relay 0.5 A, form A (cannot use variable time base)
AK None Solid-state relay 0.5 A, form A
KH Solid-state relay 0.5 A, form A NO-ARC 15 A power control
KK Solid-state relay 0.5 A, form A Solid-state relay 0.5 A, form A
Communications Options or Additional Digital I/O
None
- Standard Bus EIA-485 always included - all models
Future Options
None
Isolated Input Option
B Changes to Express
Custom Options
AA Standard EZ-ZONE face plate
12 Class 1, Div. 2 (Not available with Integrated Limit Controller or mechanical relay outputs)
Changes to C
Changes to J
