Watlow EZ-ZONE ® PM PID Controller • 75 • Chapter 7 Profiling Page
Profiling Page
Dis-
play
Parameter Name
Description
Range Default
Modbus
Relative Ad-
dress
CIP
Class
Instance
Attribute
hex (dec)
Param-
eter ID
Data
Type
&
Read/
Write
[rate]
[rAtE] Step Type Parameters
Rate
When Step Type is Rate, enter
the rate for ramping in degrees
or units per minute.
0 to 9,999.000°F or units per
minute
0 to 5,555.000°C per minute
0.0 Instance 1
Map 1 Map 2
2580 4510
Offset to next
instance (Map
1 equals +50,
Map 2 equals
+100)
0x79 (121)
1 to 40
6
21006 float
RWE
W;P1]
[W.P1] Step Type Parameters
Wait For Process 1
When Step Type is Wait for
Process or Wait For Both, enter
wait for process value for ana-
log input 1 before proceeding in
profile.
-1,999.000 to 9,999.000°F or
units
-1,128.000 to 5,537.000°C
0.0°F or
units
-18.0°C
Instance 1
Map 1
Map 2
2590 4520
Offset to next
instance (Map
1 equals +50,
Map 2 equals
+100)
0x79 (121)
1 to 40
0xB (11)
21011 float
RWE
WE;1]
[WE.1] Step Type Parameters
Wait Event 1
When Step Type is Wait for
Event or Wait For Both, select
the event state that must
be satisfied during this step.
Note:
Wait Event 1 can be mapped
to any available digital
input (5 or 6). Navigate to
the Setup Page under the
Global Menu to find and
modify Source Instance A
[`s;ia]
and Source Instance
B [`s;ib].
[`oFF] Off (62)
[``on] On (63)
[nonE] None (61)
Off Instance 1
Map 1
Map 2
2586 4516
Offset to next
instance (Map
1 equals +50,
Map 2 equals
+100)
0x79 (121)
1 to 40
9
21009 uint
RWE
[WE;2]
[WE.2] Step Type Parameters
Wait Event 2
When Step Type is Wait for
Event or Wait For Both, select
the event state that must
be satisfied during this step.
Note:
Wait Event 1 can be mapped
to any available digital
input (5 or 6). Navigate to
the Setup Page under the
Global Menu to find and
modify Source Instance A
[`s;ia]
and Source Instance
B [`s;ib].
[`oFF] Off (62)
[``on] On (63)
[nonE] None (61)
Off Instance 1
Map 1
Map 2
2588 4518
Offset to next
instance (Map
1 equals +50,
Map 2 equals
+100)
0x79 (121)
1 to 40
0xA (10)
21010 uint
RWE
[dow]
[dow] Step Type Parameters
Day of Week
When Step Type is Wait for
Time, the profile waits until
this setting (Day of Week) along
with Hours, Minutes and Sec-
onds are met.
[``ed] Every Day (1567)
[`wd] Week days (1566)
[`sun] Sunday (1565)
[mon] Monday (1559)
[`tue] Tuesday (1560)
[wed] Wednesday (1561)
[thUr] Thursday (1562)
[`fri] Friday (1563)
[`sat] Saturday (1564)
Sunday Instance 1
Map 1
Map 2
- - - - 4580
Offset to next
instance Map 2
equals +100)
0x79 (121)
1 to 40
0x29 (41)
21041 uint
RWE
Note:
Some values will be rounded off to fit in the four-character display. Full values can be read with other
interfaces. R: Read
W: Write
E: EEPROM
S: User Set
