Watlow EZ-ZONE ® PM PID Controller • 44 • Chapter 5 Operations Page
Operations Page
Display
Parameter Name
Description
Range Default Modbus Rela-
tive Address
CIP
Class
Instance
Attribute
hex (dec)
Pro-
fibus
Index
Param-
eter ID
Data
Type
&
Read/
Write
[min]
[ Min] Profile Status
Minutes
Step time remaing in
minutes.
0 to 59 0 Instance 1
Map 1 Map 2
- - - - 4492
0x7A (122)
1
0x4D (77)
- - - - 22077 uint
RW
[`seC]
[ SEC] Profile Status
Seconds
Step time remaing in
seconds.
0 to 59 0 Instance 1
Map 1 Map 2
- - - - 4490
0x7A (122)
1
0x4C (76)
- - - - 22076 uint
RW
[Ent1]
[Ent1] Profile Status
Event 1
View or change the event
output states.
[`off] Off (62)
[``on] On (63)
Off Instance 1
Map 1 Map 2
2546 4512
0x7A (122)
1
0xE (14)
- - - - 22014 uint
RW
[Ent2]
[Ent2] Profile Status
Event 2
View or change the event
output states.
[`off] Off (62)
[``on] On (63)
Off Instance 1
Map 1 Map 2
2548
4514
0x7A (122)
1
0xF (15)
- - - - 22015 uint
RW
[``JC]
[ JC] Profile Status
Jump Count Remaining
View the jump counts
remaining for the current
loop. In a profile with
nested loops, this may not
indicate the actual jump
counts remaining.
0 to 9,999 0 Instance 1
Map 1 Map 2
2538 4358
0x7A (122)
1
0xA (10)
- - - - 22010 uint
R
No Dis-
play
Profile Status
Profile State
Read currentProfile state.
off (62)
Running (149)
Pause (146) - - - - Instance 1
Map 1 Map 2
2522 4342
0x7A (122)
1
2
- - - - 22002 uint
R
No Dis-
play
Profile Status
Current File
Indicates current file be-
ing executed.
1 to 4 0 Instance 1
Map 1 Map 2
2524 4344
0x7A (122)
1
3
- - - - 22003 uint
R
Note:
Some values will be rounded off to fit in the four-character display. Full values can be
read with other interfaces. R: Read
W: Write
E: EE-
PROM
S: User
Set
