Cust, Navigating the ez-zone, Pm pid controller – Watlow EZ-ZONE PM PID User Manual
Page 35
Watlow EZ-ZONE
®
PM PID Controller
•
32
•
Chapter 4 Home Page
Applies to All Models - 1/16 DIN Shown Below
®
[``
Ai
]
[`
Set
]
®
[``
70
]
[`
`72
]
®
[``
70
]
[`
`72
]
®
[
Cust
]
[
fCty
]
Home Page from anywhere: Press the Infinity
Key ˆ for two seconds to return to the Home Page.
Factory Page from Home Page: Press both the
Advance
‰
and Infinity ˆ keys for six seconds.
®
[``
70
]
[`
`72
]
®
[``
Ai
]
[
oper
]
Operations Page from Home Page: Press both
the Up ¿ and Down ¯ keys for three seconds.
®
[``
70
]
[`
`72
]
®
[``
Ai
]
[`
Set
]
Note:
Keys must be held continuously until [`SEt]
is displayed in green. If keys are released when
[OPEr]
is displayed, press the infinity key or
reset key to exit and repeat until [`SEt] is dis-
played.
Setup Page from Home Page: Press both the
Up ¿ and Down ¯ keys for six seconds.
®
[``
70
]
[`
`72
]
®
[``
p1
]
[
prof
]
Profiling Page from Home Page: Press the
Advance Key
‰
for three seconds.
Navigating the EZ-ZONE
®
