Page 13
Watlow EZ-ZONE
®
PM PID Controller
•
10
•
Chapter 2 Install and Wire
1/8 DIN (PM9) Horizontal
(2.16 in)
54.86 mm
(3.95 in)
100.33 mm
(2.10 in)
53.34 mm
(0.62 in)
15.75 mm
(4.00 in)
101.60 mm
(0.06 in)
1.52 mm
(0.40 in)
10.16 mm
(1.21 in)
30.73 mm
1/8 DIN (PM9) Horizontal Recommended Panel Spacing
(3.62 to 3.65 inches)
Panel thickness (0.060 in) 1.53 mm
to (0.375 in) 9.52 mm
92.00 to 92.80 mm
44.96 to 45.60 mm
(1.77 to 1.79 inches)
21.6 mm
(0.85 in)
Minimum
21.6 mm
(0.85 in)
Minimum
