Watlow EZ-ZONE
®
PM PID Controller
•
54
•
Chapter 6 Setup Page
Setup Page
Dis-
play
Parameter Name
Description
Range
Default
Modbus Rela-
tive
Address
CIP
Class
Instance
Attribute
hex (dec)
Pro-
fibus
Index
Param-
eter ID
Data
Type
&
Read/
Write
[``Fn]
[ Fn]
Digital Input (5 to 6)
Action Function
Select the function that
will be triggered by a true
state for Digital Input 5
and or 6.
[none]
None (61)
[s;stp]
Start Step (1077)
[P;StS]
Profile Start/Stop,
level triggered (208)
[ProF]
Start Profile, edge
triggered (196)
[P;hoL]
Profile Hold/
Resume, level triggered
(207)
[P;diS]
Profile Disable,
level triggered (206)
[`t;da]
TRU-TUNE+
®
Dis-
able, level triggered (219)
[`oFF]
Switch Control
Loop Off, level triggered
(90)
[MAn]
Manual, level trig-
gered (54)
[tUnE]
Tune, edge trig-
gered (98)
[idLE]
Idle Set Point,
level triggered (107)
[`F;AL]
Force Alarm To Oc-
cur, level triggered (218)
[`AoF]
Control Loops Off
and Alarms to Non-alarm
State, level triggered
(220)
[`SiL]
Silence Alarms,
edge triggered (108)
[ALM]
Alarm Reset, edge
triggered (6)
[P;LoC]
Keypad Lockout,
level triggered (217)
[usr;r]
User Set Restore,
edge triggered (227)
None
Instance 5
Map 1 Map 2
1324
1564
Offset to next
instance (Map
1 & Map 2)
equals +20
0x6E (110)
5 to 6
3
138
10003
uint
RWES
[``Fi]
[ Fi]
Digital Input (5 to 6)
Function Instance
Select which Digital Input
will be triggered by a true
state.
0 to 4
0
Instance 5
Map 1 Map 2
1326
1566
Offset to next
instance (Map
1 & Map 2)
equals +20
0x6E (110)
5 to 6
4
139
10004
uint
RWES
[LooP]
[`Set]
Control Loop Menu
[`h;Ag]
[ h.Ag]
Control Loop (1)
Heat Algorithm
Set the heat control
method.
[`oFF]
Off (62)
[`Pid]
PID (71)
[on;of]
On-Off (64)
PID
Instance 1
Map 1 Map 2
1884
2364
0x97 (151)
1
3
72
8003
uint
RWES
Note:
Some values will be rounded off to fit in the four-character display. Full values can be
read with other interfaces.
R: Read
W: Write
E:
EE-
PROM
S:
User
Set
