Watlow EZ-ZONE ® PM PID Controller • 74 • Chapter 7 Profiling Page
Profiling Page
Dis-
play
Parameter Name
Description
Range Default
Modbus
Relative Ad-
dress
CIP
Class
Instance
Attribute
hex (dec)
Param-
eter ID
Data
Type
&
Read/
Write
[``P1]
[prof]
Profiling Menu
[``p1]
[ P1] to
[``p4]
[ P4] Profile [1 to 4] Step
Select a step to edit or view.
1 to 10 [profile 1]
11 to 20 [profile 2]
21 to 30 [profile 3]
31 to 40 [profile 4] - - - - - - - - - - - - - - - - - - - -
[S;typ]
[S.typ] Step Type
Select a step type.
Note:
When configuring the profile
type there will be a Time
prompt as delivered from the
factory (default). If rate is
desired navigate to the Setup
Page and then the Global Menu
where Ramping Type can be
changed.
[UStP] Unused Step (50)
[`End] End (27)
[``JL] Jump Loop (116)
[CloC] Wait For Time (1543)
[W;bo] Wait For Both (210)
[W;Pr] Wait For Process (209)
[`W;E] Wait For Event (144)
[SoAH] Soak (87)
[``ti] Time (143)
[rate] Rate (81)
Unused Instance 1
Map 1
Map 2
2570 4500
Offset to next
instance (Map
1 equals +50,
Map 2 equals
+100)
0x79 (121)
1 to 40
1
21001 uint
RWE
[t;SP1]
[t.SP1] Step Type Parameters
Target Set Point Loop 1
When Step Type is Time or
Rate, enter the Closed Loop Set
Point for loop 1 to ramp to for
this step.
-1,999.000 to 9,999.000°F or
units
-1,128 to 5,537.000°C
0.0°F or
units
-18°C
Instance 1
Map 1
Map 2
2572 4502
Offset to next
instance (Map
1 equals +50,
Map 2 equals
+100)
0x79 (121)
1 to 40
2
21002 float
RWE
[hoUr]
[hoUr] Step Type Parameters
Hours
When Step Type is Time, Soak,
or Wait For Time, enter Hours
(plus Minutes and Seconds) for
this step.
0 to 99 0 Instance 1
Map 1
Map 2
2574 4504
Offset to next
instance (Map
1 equals +50,
Map 2 equals
+100)
0x79 (121)
1 to 40
3
21003 uint
RWE
[Min]
[Min] Step Type Parameters
Minutes
When Step Type is Time, Soak,
or Wait For Time enter Minutes
(plus Hours and Seconds) for
this step.
0 to 59 0 Instance 1
Map 1
Map 2
2576 4506
Offset to next
instance (Map
1 equals +50,
Map 2 equals
+100)
0x79 (121)
1 to 40
4
21004 uint
RWE
[~SEC]
[ SEC] Step Type Parameters
Seconds
When Step Type is Time, Soak,
or Wait For Time enter Seconds
(plus Hours and Minutes) for
this step.
0 to 59 0 Instance 1
Map 1
Map 2
2578 4508
Offset to next
instance (Map
1 equals +50,
Map 2 equals
+100)
0x79 (121)
1 to 40
5
21005 uint
RWE
Note:
Some values will be rounded off to fit in the four-character display. Full values can be read with other
interfaces. R: Read
W: Write
E: EEPROM
S: User Set
