Page 64
Watlow EZ-ZONE
®
PM PID Controller
•
61
•
Chapter 6 Setup Page
Setup Page
Dis-
play
Parameter Name
Description
Range
Default
Modbus Rela-
tive
Address
CIP
Class
Instance
Attribute
hex (dec)
Pro-
fibus
Index
Param-
eter ID
Data
Type
&
Read/
Write
[`r;Lo]
[ r.Lo]
Output Process (1)
Range Low
Set the minimum value
of the retransmit value
range in process units.
When the retransmit
source is at this value, the
retransmit output will be
at its Scale Low value.
-1,999.000 to 9,999.000°F
or units
-1,128.000 to 5,537.000°C
0.0°F or
units
-18°C
Instance 1
Map 1 Map 2
740
860
0x76 (118)
1
0xB (11)
101
18011
float
RWES
[`r;hi]
[ r.hi]
Output Process (1)
Range High
Set the maximum value
of the retransmit value
range in process units.
When the retransmit
source is at this value, the
retransmit output will be
at its Scale High value.
-1,999.000 to 9,999.000°F
or units
-1,128.000 to 5,537.000°C
100°F or
units
38°C
Instance 1
Map 1 Map 2
742
862
0x76 (118)
1
0xC (12)
102
18012
float
RWES
[`o;lo]
[ o.Lo]
Output Process (1)
Output Low Power
Scale
The power output will
never be less than the
value specified and will
represent the value at
which power scaling be-
gins.
0.0 to 100%
0.0%
Instance 1
Map 1 Map 2
744
864
0x76 (118)
1
0x0D (13)
103
18013
float
RWES
[`o;hi]
[ o.hi]
Output Process (1)
Output High Power
Scale
The power output will
never be greater than the
value specified and will
represent the value at
which power scaling stops.
0.0 to 100%
100%
Instance 1
Map 1 Map 2
746
866
0x76 (118)
1
0x0E (14)
104
18014
float
RWES
[`o;CA]
[ o.CA]
Output Process (1)
Calibration Offset
Set an offset value for a
process output.
-1,999.000 to 9,999.000°F
or units
-1,110.555 to 5,555.000°C
0.0°F or
units
0.0°C
Instance 1
Map 1 Map 2
732
852
0x76 (118)
1
7
105
18007
float
RWES
[Alm]
[`Set]
Alarm Menu
[`A;ty]
[ A.ty]
Alarm (1 to 4)
Alarm Type
Select whether the alarm
trigger is a fixed value or
will track the set point.
[`oFF]
Off (62)
[PR;AL]
Process Alarm (76)
[dE;AL]
Deviation Alarm
(24)
Off
Instance 1
Map 1 Map 2
1508
1908
Offset to next
instance (Map
1 & Map 2)
equals +60
0x6D (109)
1 to 4
0xF (15)
20
9015
uint
RWES
Note:
Some values will be rounded off to fit in the four-character display. Full values can be
read with other interfaces.
R: Read
W: Write
E:
EE-
PROM
S:
User
Set
