Output menu – Watlow EZ-ZONE PM PID User Manual
Page 62
Watlow EZ-ZONE
®
PM PID Controller
•
59
•
Chapter 6 Setup Page
Setup Page
Dis-
play
Parameter Name
Description
Range
Default
Modbus Rela-
tive
Address
CIP
Class
Instance
Attribute
hex (dec)
Pro-
fibus
Index
Param-
eter ID
Data
Type
&
Read/
Write
[otpt]
[`Set]
Output Menu
[``Fn]
[ Fn]
Output Digital (1 to 2)
Output Function
Select what function will
drive this output.
[`oFF]
Off (62)
[Ent;b]
Profile Event Out
B (234)
[Ent;A]
Profile Event Out
A (233)
[Cool]
Cool (20)
[heat]
Heat (36)
[ALM]
Alarm (6)
Output 1 -
Heat
Output 2 -
Alarm
Instance 1
Map 1 Map 2
888
1008
Offset to next
instance (Map
1 & Map 2)
equals +30
0x6A (106)
1 to 2
5
83
6005
uint
RWES
[``Fi]
[ Fi]
Output Digital (1 to 2)
Output Function In-
stance
Set the instance of the
function selected above.
1 to 2
1
Instance 1
Map 1 Map 2
890
1010
Offset to next
instance (Map
1 & Map 2)
equals +30
0x6A (106)
1 to 2
6
84
6006
uint
RWES
[`o;Ct]
[ o.Ct]
Output Digital (1 to 2)
Output Control
Set the output control
type. This parameter
is only used with PID
control, but can be set
anytime.
[`Ftb]
Fixed Time Base
(34)
[`utb]
Variable Time
Base (103)
Fixed
Time
Base
Instance 1
Map 1 Map 2
882
1002
Offset to next
instance (Map
1 & Map 2)
equals +30
0x6A (106)
1 to 4
2
85
6002
uint
RWES
[`o;tb]
[ o.tb]
Output Digital (1 to 2)
Output Time Base
Set the time base for
fixed-time-base control.
0.1 to 60.0 seconds (solid-
state relay or switched
dc)
5.0 to 60.0 seconds (me-
chanical relay or no-arc
power control)
0.1 sec.
[SSR &
sw dc]
20.0 sec.
[mech,
relay,
no-arc]
Instance 1
Map 1 Map 2
884
1004
Offset to next
instance (Map
1 & Map 2)
equals +30
0x6A (106)
1 to 2
3
86
6003
float
RWES
[`o;Lo]
[ o.Lo]
Output Digital (1 to 2)
Output Low Power
Scale
The power output will
never be less than the
value specified and will
represent the value at
which output scaling
begins.
0.0 to 100.0%
0.0%
Instance 1
Map 1 Map 2
896
1016
Offset to next
instance (Map
1 & Map 2)
equals +30
0x6A (106)
1 to 2
9
87
6009
float
RWES
Note:
Some values will be rounded off to fit in the four-character display. Full values can be
read with other interfaces.
R: Read
W: Write
E:
EE-
PROM
S:
User
Set
