Watlow EZ-ZONE ® PM PID Controller • 45 • Chapter 6 Setup Page
6
Chapter 6: Setup Page
Navigating the Setup Page
To go to the Setup Page from the Home Page, press both the Up ¿ and Down ¯ keys for six seconds. [``Ai]
will appear in the upper display and [`Set] will appear in the lower display.
• Press the Up ¿ or Down ¯ key to view available menus. On the following pages top level menus are identi-
fied with a yellow background color.
•Press the Advance Key ‰ to enter the menu of choice.
• If a submenu exists (more than one instance), press the Up ¿ or Down ¯ key to select and then press the
Advance Key ‰ to enter.
• Press the Up ¿ or Down ¯ key to move through available menu prompts.
• Press the Infinity Key ˆ to move backwards through the levels: parameter to submenu; submenu to menu;
menu to Home Page.
• Press and hold the Infinity Key ˆ for two seconds to return to the Home Page.
Note:
Keys must be held continuously until [`SEt] is displayed in green. If keys are released when [OPEr] is
displayed, press the infinity key or reset key to exit and repeat until [`SEt] is displayed.
Note:
Some of these menus and parameters may not appear, depending on the controller's options. See model
number information in the Appendix for more i
[``Ai]
[`Set]
Analog Input Menu
[`SEn] Sensor Type
[`Lin] TC Linearization
[`rt;L] RTD Leads
[Unit] Units
[`S;Lo] Scale Low
[`S;hi] Scale High
[`r;Lo] Range Low
[`r;hi] Range High
[`P;EE] Process Error Enable
[`P;EL] Process Error Low Value
[``t;C] Thermistor Curve
[``r;r] Resistance Range
[`FiL] Filter
[`i;er] Error Latching
[`dEC] Display Precision
[`i;Ca] Calibration Offset **
[`Ain] Analog Input Value **
[`i;Er] Input Error Status **
[`Lnr]
[`Set]
Linearization Menu
[``Fn] Function
[Unit] Units
[`ip;1] Input Point 1
[`op;1] Output Point 1
[`ip;2] Input Point 2
[`op;2] Output Point 2
[`ip;3] Input Point 3
[`op;3] Output Point 3
[`ip;4] Input Point 4
[`op;4] Output Point 4
[`ip;5] Input Point 5
[`op;5] Output Point 5
[`ip;6] Input Point 6
[`op;6] Output Point 6
[`ip;7] Input Point 7
[`op;7] Output Point 7
[`ip;8] Input Point 8
[`op;8] Output Point 8
[`ip;9] Input Point 9
[`op;9] Output Point 9
[ip;10] Input Point 10
[op;10] Output Point 10
[``Pu]
[`Set]
Process Value
[``Fn] Function
[P;unt] Pressure Units
[A;unt]
Altitude Units
[[`FiL] Filter
[`dio]
[`Set]
Digital Input/Output Menu
[```5]
[`dio]
Digital Input/Output (5 to 6)
[`dir] Direction
[``Fn] Output Function
[``Fi] Output Function Instance
[`o;Ct] Output Control
[`o;tb] Output Time Base
[`o;Lo] Output Low Power Scale
[`o;hi] Output High Power Scale
[[Loop]
[`Set]
Control Loop Menu
[`h;Ag] Heat Algorithm
[`C;Ag] Cool Algorithm
[`C;Cr] Cool Output Curve
[`h;Pb] Heat Proportional Band **
[`h;hy]
Heat Hysteresis **
[`C;Pb] Cool Proportional Band **
[`C;hy] Cool Hysteresis **
[``ti] Time Integral **
[``td] Time Derivative **
[``db] Dead Band **
[t;tUn] Tru-Tune+™ Enable
[t;bnd] Tru-Tune+™ Band
[`t;gn] Tru-Tune+™ Gain
[A;tSP] Autotune Set Point
[t;Agr]
Autotune Aggressiveness
[`P;dl] Peltier Delay
[`UFA]
User Failure Action
[FAiL] Input Error Failure
[MAn] Fixed Power
[`L;dE] Open Loop Detect Enable
[`L;dt] Open Loop Detect Time
[`L;dd] Open Loop Detect Deviation
[``rp] Ramp Action
[`r;SC] Ramp Scale
[`r;rt] Ramp Rate
[`L;SP] Low Set Point
[`h;SP] High Set Point
[`C;SP] Closed Loop Set Point **
[`id;S]
Idle Set Point **
[SP;Lo] Set Point Open Limit Low
[SP;hi] Set Point Open Limit High
[`o;SP] Open Loop Set Point **
[`C;M] Control Mode **
[otpt]
[`Set]
Output Menu
[```1]
[otpt]
Output (1 to 2)
[``Fn] Output Function
[``Fi] Output Function Instance
[`o;Ct] Output Control
[`o;tb] Output Time Base
** These parameters/prompts are available with firmware revisions 11.0 and above.
