Watlow EZ-ZONE ® PM PID Controller • 116 • Appendix
Ordering Information for PID Controller Models
Controller P M __ __ __ __ __ - __ A A A __ __ __
EZ-ZONE ® PID Controller Models
TRU-TUNE+ ® Adaptive Tune, red-green 7-segment displays
Package Size
3 Panel Mount 1/32 DIN
6 Panel Mount 1⁄16 DIN
8 Panel Mount 1⁄8 DIN Vertical
9 Panel Mount 1⁄8 DIN Horizontal
4 Panel Mount 1⁄4 DIN Horizontal
Primary Function
C PID Controller with Universal Input
R PID Controller with Universal Input and Profiling Ramp and Soak
B PID Controller with Universal Input and Profiling Ramp and Soak
and Battery Backup with Real Time Clock
J PID Controller with Thermistor Input
N PID Controller with Thermistor Input and Profiling Ramp and Soak
E PID Controller with Thermistor Input and Profiling Ramp and Soak
and Battery Backup with Real Time Clock
S Custom Firmware
- Options B and E are not available with PM3 or PM6
Power Supply, Digital Input/Output
1 100 to 240V Å (ac)
2 100 to 240V Å (ac) plus 2 Digital I/O points
3 15 to 36V Î (dc) and 24VÅ (ac)
4 15 to 36V Î (dc) and 24VÅ (ac), plus 2 Digital I/O points
Output 1 and 2 Hardware Options
Output 1 Output 2
CA Switched dc/open collector None
CH Switched dc/open collector NO-ARC 15 A power control
CC Switched dc/open collector Switched dc
CJ Switched dc/open collector Mechanical relay 5 A, form A
CK Switched dc/open collector Solid-State Relay 0.5 A, form A
EA Mechanical relay 5 A, form C None
EH Mechanical relay 5 A, form C NO-ARC 15 A power control
EC Mechanical relay 5 A, form C Switched dc
EJ Mechanical relay 5 A, form C Mechanical relay 5 A, form A
EK Mechanical relay 5 A, form C Solid-State Relay 0.5 A, form A
FA Universal process None
FC Universal process Switched dc (cannot use variable time base)
FJ Universal process Mechanical relay 5 A, form A (cannot use variable time base)
FK Universal process Solid-State Relay 0.5 A, form A (cannot use variable time base)
AK None Solid-State Relay 0.5 A, form A
KH Solid-State Relay 0.5 A, form A NO-ARC 15 A power control
KK Solid-State Relay 0.5 A, form A Solid-state relay 0.5 A, form A
- Options CH, EH and KH are not available with PM3 (1/32 DIN)
Communications Options
A None
1 EIA 485 Modbus RTU ®
- Standard Bus EIA-485 always included - all models
Future Options
AAA None
Isolated Input Option
A None
D Isolated Input 1
Custom Options
AA Standard EZ-ZONE face plate
12 Class 1, Div. 2 (Not available with mechanical relay output types E, H, J)
