Watlow EZ-ZONE ® PM PID Controller • 66 • Chapter 6 Setup Page
Setup Page
Dis-
play
Parameter Name
Description
Range Default
Modbus Rela-
tive
Address
CIP
Class
Instance
Attribute
hex (dec)
Pro-
fibus
Index
Param-
eter ID
Data
Type
&
Read/
Write
[R;typ]
[R.tyP]
Global
Ramping Type
[rate] Rate (81)
[``ti] Time (143)
Time Instance 1
Map 1 Map 2
- - - - 4414
0x7A (122)
1
26 (38)
- - - - 22038 uint
RWE
[P;typ]
[P.tyP]
Global
Profile Type
Set the profile startup to
be based on a set point or
a process value.
[StPt] Set Point (85)
[`Pro] Process (75)
Set Point Instance 1
Map 1 Map 2
2534 4354
0x7A (122)
1
8
- - - - 22008 uint
RWE
[`GSE]
[ gSE]
Global
Guaranteed Soak En-
able
Enables the guaranteed
soak deviation function in
profiles.
[`oFF] Off (62)
[``on] On (63)
Off Instance 1
Map 1 Map 2
2530 4350
0x7A (122)
1
6
- - - - 22006 uint
RWE
[GSd1]
[gSd1]
Global
Guaranteed Soak De-
viation 1
Set the value of the de-
viation band that will be
used in all profile step
types. The process value
must enter the deviation
band before the step can
proceed.
0.0 to 9,999.000°F or units
0.0 to 5,555.000°C 10.0°F or
units
6.0°C
Instance 1
Map 1 Map 2
2532 4352
0x7A (122)
1
7
- - - - 22007 float
RWE
[`Si;a]
[ Si.a] Global
Source Instance A
Set the digital source
for Wait for Event 1 in
profile.
5 to 6 5 Instance 1
Map 1 Map 2
- - - - 4390
0x7A (122)
1
0x1A (26)
- - - - 22060 uint
RWES
[`Si;B]
[ Si.b] Global
Source Instance B
Set the digital source
for Wait for Event 2 in
profile.
5 to 6 5 Instance 1
Map 1 Map 2
- - - - 4392
7A (122)
1
0x1B (27)
- - - - 22061 uint
RWES
[poti]
[Poti] Global
Power Off Time
If profile is running and
power is lost, profile
will resume where it
left off provided time set
has not expired prior to
power restoration.
0 to 9999 seconds 0 Instance 1
Map 1 Map 2
- - - - 4484
7A (122)
1
0x49 (73)
- - - - 22073 uint
RWE
[sutb]
[Sutb] Global
Synchronized Variable
Time Base
Used to acquire tighter
accuracy when running
a profile. A setting of
+0.01 would equate to
approximately +9 sec-
onds/day (faster) where
a setting of -0.01 would
equate to approximately
-9 seconds/day (slower).
-2.00 to 2.00 Percent 0.00 - - - - - - - - - - - - - - - - float
RWES
Note:
Some values will be rounded off to fit in the four-character display. Full values can be
read with other interfaces. R: Read
W: Write
E: EE-
PROM
S: User
Set
