Watlow EZ-ZONE ® PM PID Controller • 31 • Chapter 4 Home Page
Home Page Defaults
Home Page
Display
Parameter Page and Menu
All Models
1 Active Process Value (1)
Numerical
value
Operations Page, Monitor Menu
2 Active Set Point (1)
Numerical
value
Operations Page, Monitor Menu
3 Control Mode (1)
[C;M1]
Operations Page, Monitor Menu
4 Heat Power (1) [h;pr1] Operations Page, Monitor Menu
5 Cool Power (1) [C;pr1] Operations Page, Monitor Menu
6 Autotune (1) [aut1] Operations Page, Loop Menu
7 Idle Set Point (1)
[id;s1]
Operations Page, Loop Menu
8 * Profile Start
[p;st1]
9 * Action Request [p;aC1]
10 None
11 None
12 None
13 None
14 None
15 None
16 None
17 None
18 None
19 None
20 None
* The fourth digit of the part number must be:
PM _ [R, B, N or E] _ _ _ - _ _ _ _ _ _ _
Note:
The numerical digit shown in the prompts (last digit) and within the parentheses above, represents the pa-
rameter instance and can be greater than one.
