Watlow EZ-ZONE PM PID User Manual
Page 56
Watlow EZ-ZONE
®
PM PID Controller
•
53
•
Chapter 6 Setup Page
Setup Page
Dis-
play
Parameter Name
Description
Range
Default
Modbus Rela-
tive
Address
CIP
Class
Instance
Attribute
hex (dec)
Pro-
fibus
Index
Param-
eter ID
Data
Type
&
Read/
Write
[`o;Lo]
[ o.Lo]
Digital Output (5 to 6)
Output Low Power
Scale
The power output will
never be less than the
value specified and will
represent the value at
which output scaling
begins.
0.0 to 100.0
0.0
Instance 5
Map 1 Map 2
1016
1136
Offset to next
instance (Map
1 & Map 2)
equals +30
0x6A (106)
5 to 6
9
87
6009
float
RWES
[`o;hi]
[ o.hi]
Digital Output (5 to 6)
Output High Power
Scale
The power output will
never be greater than
the value specified and
will represent the value
at which output scaling
stops.
0.0 to 100.0
100.0
Instance 5
Map 1 Map 2
1018
1138
Offset to next
instance (Map
1 & Map 2)
equals +30
0x6A (106)
5 to 6
0xA (10)
88
6010
float
RWES
[`leu]
[ LEv]
Digital Input (5 to 6)
Action Level
Select which action will
be interpreted as a true
state.
[high]
High (37)
[LoW]
Low (53)
High
Instance 5
Map 1 Map 2
1320
1560
Offset to next
instance (Map
1 & Map 2)
equals +20
0x6E (110)
5 to 6
1
137
10001
uint
RW
Note:
Some values will be rounded off to fit in the four-character display. Full values can be
read with other interfaces.
R: Read
W: Write
E:
EE-
PROM
S:
User
Set
