Page 68
Watlow EZ-ZONE
®
PM PID Controller
•
65
•
Chapter 6 Setup Page
Setup Page
Dis-
play
Parameter Name
Description
Range
Default
Modbus Rela-
tive
Address
CIP
Class
Instance
Attribute
hex (dec)
Pro-
fibus
Index
Param-
eter ID
Data
Type
&
Read/
Write
[``Fn]
[ Fn]
Function Key (1 to 2)
Action Function
Program the EZ Key to
trigger an action.
Functions respond to a
level state change or an
edge level change.
[none]
None (61)
[usr;r]
User Set Restore,
edge triggered (227)
[P;LoC]
Keypad Lockout,
level triggered (217)
[ALM] Alarm Reset, edge
triggered (6)
[`SiL]
Silence Alarms,
edge triggered (108)
[`AoF]
Control Loops Off
and Alarms to Non-alarm
State, level triggered
(220)
[`F;AL]
Force Alarm To Oc-
cur, level triggered (218)
[idLE]
Idle Set Point,
level triggered (107)
[tUnE]
Tune, edge trig-
gered (98)
[MAn]
Manual Mode,
level triggered (54)
[`oFF]
Switch Control
Loop Off, level triggered
(90)
[`t;da]
TRU-TUNE+
®
Dis-
able, level triggered (219)
[P;diS]
Profile Disable,
level triggered (206)
[P;hoL]
Profile Hold/
Resume, level triggered
(207)
[ProF]
Start Profile, edge
triggered (196)
[P;StS]
Profile Start/Stop,
level triggered (208)
[s;stp]
Start Step (1077)
None
Instance 1
Map 1 Map 2
1364
1604
Instance 2
Map 1 Map 2
1384 1624
0x6E (110)
1 to 2
3
138
10003
uint
RWES
[``Fi]
[ Fi]
Function Key (1 to 2)
Function Instance
Select which instance the
EZ Key will affect. If only
one instance is available,
any selection will affect it.
0 to 4
0
Instance 1
Map 1 Map 2
1364
1606
Instance 2
Map 1 Map 2
1384 1626
0x96 (110)
1 to 2
4
139
10004
uint
RWES
[gLbL]
[`Set]
Global Menu
[`C_F]
[ C_F]
Global
Display Units
Select which scale to use
for temperature.
[```F]
°F (30)
[```C]
°C (15)
°F
Instance 1
Map 1 Map 2
1838
2308
0x67 (103)
1
5
110
3005
uint
RWES
[AC;LF]
[AC.LF]
Global
AC Line Frequency
Set the frequency to the
applied ac line power
source.
[``50]
50 Hz (3)
[``60]
60 Hz (4)
60 Hz
Instance 1
Map 1 Map 2
886
1006
0x6A (106)
1
4
89
1034
uint
RWES
Note:
Some values will be rounded off to fit in the four-character display. Full values can be
read with other interfaces.
R: Read
W: Write
E:
EE-
PROM
S:
User
Set
