Watlow EZ-ZONE PM PID User Manual
Page 63
Watlow EZ-ZONE
®
PM PID Controller
•
60
•
Chapter 6 Setup Page
Setup Page
Dis-
play
Parameter Name
Description
Range
Default
Modbus Rela-
tive
Address
CIP
Class
Instance
Attribute
hex (dec)
Pro-
fibus
Index
Param-
eter ID
Data
Type
&
Read/
Write
[`o;hi]
[ o.hi]
Output Digital (1 to 2)
Output High Power
Scale
The power output will
never be greater than
the value specified and
will represent the value
at which output scaling
stops.
0.0 to 100.0%
100.0%
Instance 1
Map 1 Map 2
898
1018
Offset to next
instance (Map
1 & Map 2)
equals +30
0x6A (106)
1 to 2
0xA (10)
88
6010
float
RWES
[`o;ty]
[ o.ty]
Output Process (1)
Output Type
Select whether the pro-
cess output will operate in
volts or milliamps.
[uoLt]
Volts (104)
[`MA]
Milliamps (112)
Volts
Instance 1
Map 1 Map 2
720
840
0x76 (118)
1
1
95
18001
uint
RWES
[``Fn]
[ Fn]
Output Process (1)
Output Function
Set the type of function
that will drive this out-
put.
[`oFF]
Off (62)
[dupl]
Duplex (212)
[Cool]
Cool (20)
[heat]
Heat (36)
[rmt]
Retransmit (213)
[Ent;b]
Profile Event Out
B (234)
[Ent;A]
Profile Event Out
A (233)
[ALM]
Alarm (6)
Off
Instance 1
Map 1 Map 2
722
842
0x76 (118)
1
2
96
18002
uint
RWES
[`r;Sr]
[ r.Sr]
Output Process (1)
Retransmit Source
Select the value that will
be retransmitted.
[``Ai]
Analog Input (142)
[StPt]
Set Point (85)
[CUrr]
Current (22)
[``Pu]
Process Value
(241)
Analog
Input
Instance 1
Map 1 Map 2
724
844
0x76 (118)
1
3
97
18003
uint
RWES
[``Fi]
[ Fi]
Output Process (1)
Output Function In-
stance
Set the instance of the
function selected above.
1 to 4
1
Instance 1
Map 1 Map 2
726
846
0x76 (118)
1
4
98
18004
uint
RWES
[`S;Lo]
[ S.Lo]
Output Process (1)
Scale Low
Set the scale low for pro-
cess output in electrical
units. This value; in volts
or milliamps, will cor-
respond to 0% PID power
output or range low re-
transmit output.
-100.0 to 100.0
0.00
Instance 1
Map 1 Map 2
736
856
0x76 (118)
1
9
99
18009
float
RWES
[`S;hi]
[ S.hi]
Output Process (1)
Scale High
Set the scale high for pro-
cess output in electrical
units. This value; in volts
or milliamps, will corre-
spond to 100% PID power
output or range high
retransmit output. .
-100.0 to 100.0
10.00
Instance 1
Map 1 Map 2
738
858
0x76 (118)
1
0xA (10)
100
18010
float
RWES
Note:
Some values will be rounded off to fit in the four-character display. Full values can be
read with other interfaces.
R: Read
W: Write
E:
EE-
PROM
S:
User
Set
