Watlow EZ-ZONE

PM PID Controller

•

Chapter 8 Factory Page

Factory Page

Dis-

play

Parameter Name

Description

Range

Default

Modbus

Relative Ad-

dress

CIP

Class

Instance

Attribute

hex (dec)

Profibus

Index

Param-

eter ID

Data

Type

Read/

Write

[Cust]
[fcty]
Custom Menu

[`par]
[ Par]

Custom

Parameter 1 to 20

Select the parameters that

will appear in the Home

Page.

The Parameter 1 value will

appear in the upper dis-

play of the Home Page. It

cannot be changed with

the Up and Down Keys

in the Home Page.

The Parameter 2 value will

appear in the lower dis-

play in the Home Page. It

can be changed with the

Up and Down Keys, if the

parameter is a writable

one.

Scroll through the other

Home Page parameters

with the Advance Key

‰

Note:

Display Pairs affect the

pairing of custom pa-

rameters on the Home

page. For more informa-

tion on Display Pairs see

the section in this guide

entitled "Modifying the

Display Pairs"

[nonE]

None

[`Pro]

Process

[`i;CA]

Calibration Offset

[`C_F]

Display Units

[USr;r]

User Settings Re-

store

[`A;Lo]

Alarm Low Set

Point

[`A;hi]

Alarm High Set

Point

[`A;hy]

Alarm Hysteresis

[CUSt]

Custom Menu

[StPt]

Set Point

[AC;pu]

Active Process

Value

[AC;SP]

Active Set Point

[``op]

Open Loop Set

Point

[`AUt]

Autotune

[`C;M]

Control Mode

[`h;Pr]

Heat Power

[`C;Pr]

Cool Power

[``ti]

Time Integral

[``td]

Time Derivative

[``db]

Dead Band

[`h;Pb]

Heat Proportional

Band

[`h;hy]

Heat Hysteresis

[`C;Pb]

Cool Proportional

Band

[`C;hy]

Cool Hysteresis

[`r;rt]

Ramp Rate

[t;tUn]

TRU-TUNE+

En-

able

[idLE]

Idle Set Point

[P;Str]

Profile Start

[P;ACr]

Profile Action Re-

quest

[gSd1]

Guaranteed Soak

Deviation 1

See:

Home

Page

- - - -

14005

uint

RWES

[`iid]

[ iid]

Custom (1 to 20)

Instance ID

Select which instance of

the parameter will be se-

lected.

1 to 4

- - - -

14003

uint

RWES

[`LoC]
[FCty]
Security Setting Menu

[LoC;o]
[LoC.o]

Security Setting

Operations Page

Change the security level

of the Operations Page.

1 to 3

- - - -

3002

uint

RWE

Note:

Some values will be rounded off to fit in the four-character display. Full values can be
read with other interfaces.

If there is only one instance of a menu, no submenus will appear .

R: Read

W: Write

EEPROM

User

Set
