Watlow EZ-ZONE PM PID - Manual (Page 79)

Watlow EZ-ZONE ® PM PID Controller • 76 • Chapter 7 Profiling Page
Profiling Page
Dis-
play
Parameter Name
Description
Range Default
Modbus
Relative Ad-
dress
CIP
Class
Instance
Attribute
hex (dec)
Param-
eter ID
Data
Type
&
Read/
Write
[~~JS]
[ JS] Step Type Parameters
Jump Step
When Step Type is Jump Loop,
this setting specifies which step
to jump back to. Jump Step
must be a lower step number
than the current step number.
1 to 40 0 Instance 1
Map 1
Map 2
2592 4522
Offset to next
instance (Map
1 equals +50,
Map 2 equals
+100)
0x79 (121)
1 to 40
0xC (12)
21012 uint
RWE
[~~JC]
[ JC] Step Type Parameters
Jump Count
When Step Type is Jump Loop,
this specifies the number of
jumps to repeat. A value
of 0 creates an infinite loop.
Loops can be nested four deep.
0 to 9,999 0 Instance 1
Map 1
Map 2
2594 4524
Offset to next
instance (Map
1 equals +50,
Map 2 equals
+100)
0x79 (121)
1 to 40
0xD (13)
21013 uint
RWE
[~End]
[ End] Step Type Parameters
End Type
When Step Type is End, this
setting specifies what the con-
troller will do when this profile
ends.
Note:
End Hold does not affect the
control mode, only the closed
loop set point. The profile will
return to the control mode be-
fore a profile was started.
[`oFF] Control Mode set to Off
(62)
[Hold] Hold last closed-loop set
point in the profile (47)
[USEr] User, reverts to previ-
ous set point (100)
Off Instance 1
Map 1
Map 2
2596 4526
Offset to next
instance (Map
1 equals +50,
Map 2 equals
+100)
0x79 (121)
1 to 40
0xE (14)
21014 uint
RWE
Ent1]
[Ent1] Step Type Parameters
Event 1
When Step Type is not Unused
Step, select whether Event Out-
put 1 or 2 is on or off during
this step.
[`oFF] Off (62)
[``on] On (63)
Off Instance 1
Map 1
Map 2
2582 4512
Offset to next
instance (Map
1 equals +50,
Map 2 equals
+100)
0x79 (121)
1 to 40
7
21007 uint
RWE
[Ent2]
[Ent2] Step Type Parameters
Event 2
When Step Type is not Unused
Step, select whether Event Out-
put 1 or 2 is on or off during
this step.
[`oFF] Off (62)
[``on] On (63)
Off Instance 1
Map 1
Map 2
2584 4514
Offset to next
instance (Map
1 equals +50,
Map 2 equals
+100)
0x79 (121)
1 to 40
8
21008 uint
RWE
Note:
Some values will be rounded off to fit in the four-character display. Full values can be read with other
interfaces. R: Read
W: Write
E: EEPROM
S: User Set
