Watlow EZ-ZONE ® PM PID Controller • 47 • Chapter 6 Setup Page
Setup Page
Dis-
play
Parameter Name
Description
Range Default
Modbus Rela-
tive
Address
CIP
Class
Instance
Attribute
hex (dec)
Pro-
fibus
Index
Param-
eter ID
Data
Type
&
Read/
Write
[``Ai]
[`Set]
Analog Input Menu
[`Sen]
[ SEn] Analog Input (1)
Sensor Type
Set the analog sensor type
to match the device wired
to this input.
Note:
There is no open-sensor de-
tection for process inputs.
[`oFF] Off (62)
[``tC] Thermocouple (95)
[`mu] Millivolts (56)
[uolT] Volts dc (104)
[`MA] Milliamps dc (112)
[r0;1H] RTD 100 Ω (113)
[r1;0H] RTD 1,000 Ω (114)
[`Pot] Potentiometer 1
kΩ (155)
[thEr] Thermistor (229)
Instance 1
Map 1 Map 2
368 368
0x68 (104)
1
5
3 4005 uint
RWES
[`Lin]
[ Lin] Analog Input (1)
TC Linearization
Set the linearization to
match the thermocouple
wired to this input.
[```b] B (11) [```H] K (48)
[```C] C (15) [```n] N (58)
[```d] D (23) [```r] R (80)
[```E] E (26) [```S] S (84)
[```F] F (30) [```t] T (93)
[```J] J (46)
J Instance 1
Map 1 Map 2
370 370
0x68 (104)
1
6
4 4006 uint
RWES
[`Rt;L]
[ rt.L] Analog Input (1)
RTD Leads
Set to match the number
of leads on the RTD wired
to this input.
[```2] 2 (1)
[```3] 3 (2)
2 Instance 1
Map 1 Map 2
372 372
0x68 (104)
1
7
- - - - 4007 uint
RWES
[Unit]
[Unit] Analog Input (1)
Units
Set the type of units the
sensor will measure.
[`A;tP] Absolute Tempera-
ture (1540)
[``rh] Relative Humidity
(1538)
[`Pro] Process (75)
[PWr] Power (73)
Process Instance 1
Map 1 Map 2
- - - - 442
0x68 (104)
1
0x2A (42)
5 4042 uint
RWES
[`S;Lo]
[ S.Lo] Analog Input (1)
Scale Low
Set the low scale for pro-
cess inputs. This value,
in millivolts, volts or mil-
liamps, will correspond to
the Range Low output of
this function block.
-100.0 to 1,000.0 0.0 Instance 1
Map 1 Map 2
388 388
0x68 (104)
1
0xF (15)
6 4015 float
RWES
[`S;hi]
[ S.hi] Analog Input (1)
Scale High
Set the high scale for
process inputs. This value,
in millivolts, volts or mil-
liamps, will correspond to
the Range High output of
this function block.
-100.0 to 1,000.0 20.0 Instance 1
Map 1 Map 2
390 390
0x68 (104)
1
0x10 (16)
7 4016 float
RWES
[`r;Lo]
[ r.Lo] Analog Input (1)
Range Low
Set the low range for this
function block's output.
-1,999.000 to 9,999.000 0.0 Instance 1
Map 1 Map 2
392 392
0x68 (104)
1
0x11 (17)
8 4017 float
RWES
Note:
Some values will be rounded off to fit in the four-character display. Full values can be
read with other interfaces. R: Read
W: Write
E: EE-
PROM
S: User
Set
