Environmental Specifications
Air quality requirements
Do not operate or store the GP unit where chemicals evaporate, or where chemicals
are present in the air:
z
Corrosive chemicals: Acids, alkalines, liquids containing salt.
z
Flammable chemicals: Organic solvents.
DC Model
AC Model
GP-4501T / GP-4503T
GP-4501TW
Physi
cal Env
ironment
Surrounding Air
Temperature
0...55 °C (32...131 °F)
0...50 °C (32...122 °F)
0...55 °C (32...131 °F)
Storage Temperature
-20...60 °C (-4...140 °F)
Surrounding Air and
Storage Humidity
10...90% RH (Non condensing, wet bulb temperature 39 °C [102.2 °F] or less)
Dust
0.1 mg/m
3
(10
-7
oz/ft
3
) or less (non-conductive levels)
Pollution Degree
For use in Pollution Degree 2 environment
Corrosive Gases
Free of corrosive gases
Atmospheric Pressure
(Operating Altitude)
800...1,114 hPa (2,000 m [6,561 ft] or lower)
Mech
anical Environme
nt
Vibration Resistance
IEC/EN 61131-2 compliant
5...9 Hz Single amplitude 3.5 mm (0.14 in.)
9...150 Hz Fixed acceleration: 9.8 m/s
2
X, Y, Z directions for 10 cycles (approx. 100 min)
Concussion Resistance IEC/EN 61131-2 compliant
147 m/s
2
, X, Y, Z directions for 3 times
Electrical Envir
onment
Noise Immunity
Noise Voltage: 1,000 Vp-p
Pulse Width: 1 µs
Rise Time: 1 ns
Noise Voltage: 1,500 Vp-p
Pulse Width: 1 µs
Rise Time: 1 ns
Electrostatic Discharge
Immunity
Contact Discharge Method: 6 kV (IEC/EN 61000-4-2 Level 3)
CAUTION
INOPERATIVE EQUIPMENT
Do not allow water, liquids, metal, and wiring fragments to enter the panel case.
Failure to follow these instructions can result in injury or equipment damage.
