Proface GP4600R - 12.1 Standard HMIs with Rear Mounting Options" - Manual (Page 226)

226
Unit mm[in.]
Note: Note that the panel cut dimensions have been calculated with the display
area, not the panel cut (A or B), as the reference.
Attaching Installation Brackets on
the Top and Bottom Surfaces of
the GP Unit
Attaching Installation Brackets on
the Sides of the GP Unit
X1 Y1 X2 Y2
PFXGP4301TADR 43 (±0.15)
[1.69, (±0.01)]
69.5 (±0.15)
[2.74, (±0.01)] 85.6 (±0.15)
[3.37, (±0.01)] 43 (±0.15)
[1.69, (±0.01)]
PFXGP4401TADR 43 (±0.15)
[1.69, (±0.01)]
87.5 (±0.15)
[3.45, (±0.01)] 109.8 (±0.15)
[4.32, (±0.01)] 43 (±0.15)
[1.69, (±0.01)]
PFXGP4501TADR 75.5 (±0.15)
[2.97, (±0.01)]
108.55 (±0.15)
[4.27, (±0.01)] 137.65 (±0.15)
[5.42, (±0.01)] 75.5 (±0.15)
[2.97, (±0.01)]
PFXGP4601TADR 75.5 (±0.15)
[2.97, (±0.01)]
121.8 (±0.15)
[4.80, (±0.01)] 158.8 (±0.15)
[6.25, (±0.01)] 75.5 (±0.15)
[2.97, (±0.01)]
