GP4000 Series Hardware Manual
77
Dimensions
NOTE:
z
If you are using the rear mount model, refer to Dimensions (see page 184).
External Dimensions
1
Front
2
Right Side
3
Top
137
169.5
155.5
123
59.5
5
6.12
4.84
2.34
6.67
5.39
0.20
mm
in.
(1)
(3)
(GP-4301T)
(2)
