GP4000 Series Hardware Manual
129
Dimensions
NOTE:
z
If you are using the rear mount model, refer to Dimensions (see page 184).
External Dimensions
1
Front
2
Right Side
3
Top
301
11.85
315
12.40
56
2.20
5
0.20
241 9.49
227 8.94
mm
in.
(1)
(3)
(2)
(GP-4601T)
