Parts Identification and Functions
Parts Identification and Functions
GP-4200 Series Parts Identification
Side
GP-4200 Series
Front
Rear
Bottom
Part
Name
Description
A
Status LED
*1
B
USB (mini-B) Interface
Conforms to USB2.0 (mini-B) x 1.
Communication Distance: 5 m (16.4 ft) or
less.
A
B
C
GP-4201T/4203T
GP-4201TW
F
E
D
F
G
D
