Type 6 Carrier Board Design Guide

Page 83

chassis ground through the heat sink andor heatspreader. System designers should take

this into account when defining system grounding.

5.7 Others Kits Specification

5.7.1 Cooling Kit

IEI provides a standard cooling kit specially designed for the COM Express Type 6

modules. The cooling kit includes a heatspreader plate and a heat sink. The cooling kit

dimensions and photos are shown below.

Figure 5-11: IEI Heat Sink Module Dimensions

Heatsink Heatspreader Plate

Figure 5-12: IEI Heat Sink Module Picture
