Type 6 Carrier Board Design Guide
Page 43
layers with USB 2.0 traces as much as practical. It is preferable to change layers
to avoid crossing a plane split. USB 2.0 traces as much as practical. It is
preferable to change layers to avoid crossing a plane split.
ƒ Separate signal traces into similar categories, and route similar signal traces
together (such as routing differential pairs together).
ƒ Keep USB 2.0 signals clear of the core logic set. High current transients are
produced during internal state transitions and can be very difficult to filter out.
3.5 DDI
The COM Express Types 6 Module uses Digital Display Interfaces (DDI) to provide
DisplayPort, HDMI/DVI, and SDVO interfaces. Type 6 Modules can contain up to 3 DDIs
of which DDI 1~3 can support DisplayPort, HDMI/DVI and DDI 1 can support DisplayPort,
HDMI/DVI, and SDVO. Please note that the SDVO is only supported on DDI 1 for Type 6
Modules.
3.5.1 Signal Description
Pin Signal I/O Description
D26
D27 DDI1_PAIR0+
DDI1_PAIR0- O PCIe DDI 1. Transmit Output differential pair 0.
D29
D30 DDI1_PAIR1+
DDI1_PAIR1- O PCIe DDI 1. Transmit Output differential pair 1.
D32
D33 DDI1_PAIR2+
DDI1_PAIR2- O PCIe DDI 1. Transmit Output differential pair 2.
D36
D37 DDI1_PAIR3+
DDI1_PAIR3- O PCIe DDI 1. Transmit Output differential pair 3.
C25
C26 DDI1_PAIR4+
DDI1_PAIR4- O PCIe DDI 1. Transmit Output differential pair 4.
C29
C30 DDI1_PAIR5+
DDI1_PAIR5- O PCIe DDI 1. Transmit Output differential pair 5.
C15
C16 DDI1_PAIR6+
DDI1_PAIR6- O PCIe DDI 1. Transmit Output differential pair 6.
D39
D40 DDI2_PAIR0+
DDI2_PAIR0- O PCIe DDI 2. Transmit Output differential pair 0.
D42
D43 DDI2_PAIR1+
DDI2_PAIR1- O PCIe DDI 2. Transmit Output differential pair 1.
D46
D47 DDI2_PAIR2+
DDI2_PAIR2- O PCIe DDI 2. Transmit Output differential pair 2.
D49
D50 DDI2_PAIR3+
DDI2_PAIR3- O PCIe DDI 2. Transmit Output differential pair 3.
C39
C40 DDI3_PAIR0+
DDI3_PAIR0- O PCIe DDI 3. Transmit Output differential pair 0.
C42 DDI3_PAIR1+ O PCIe DDI 3. Transmit Output differential pair 1.
