Type 6 Carrier Board Design Guide
Page 7
1.4 ICE-DB-T6 Reference Carrier Board
The ICE-DB-T6 is a full function carrier board for customers to apply or test the COM
Express Type 6 module. The carrier board can be used for any combination, including
software and hardware. Using the carrier board to develop and test the Type 6 module
also can achieve a quicker time to market. The ICE-DB-T6 is shown in Figure 1-3 and the
specifications are listed in Table 1-3.
Figure 1-3: ICE-DB-T6
1.4.1 ICE-DB-T6 Specifications
The ICE-DB-T6 technical specifications are listed below.
Specifications/Model ICE-DB-T6 Reference Carrier Board
Form Factor ATX form factor baseboard
CPU
Support COM Express compact/basic module using Type 6
connector
Super I/O
Winbond W83627DHG
