background image

Type 6 Carrier Board Design Guide

Page 6

Specifications/Model ICE-CV-D25501/N26001

BIOS

UEFI BIOS

USB 3.0

ASMedia ASM1042

Embedded Controller iWDD

Watchdog Timer

Software programmable supports 1~255 sec. system reset

Expansion

Four PCIe x1 (signal to baseboard)

I/O Interfaces

(Signal to Baseboard)

Two USB 3.0

Eight USB 2.0

Two SATA 3Gb/s

Two UART (by EC)

HD Audio

GPIO

SMBus

I2C

LPC

SPI

Power Consumption

+12V @ 0.45 A , Vcore_12V @ 1.0A (1.86 GHz Intel® Atom™ D2550

CPU with 2 GB 1066 MHz DDR3 SO-DIMM)

Operating

Temperature

-10ºC ~ 60ºC

Storage Temperature -20ºC ~ 70ºC

Humidity (Operating)

5% ~ 95% (non-condensing)

Dimensions

95 mm x 95 mm

Weight (GW/NW)

600 g/200 g

Table 1-2: ICE-CV-D25501/N26001 Specifications
