Type 6 Carrier Board Design Guide
Page 3
1.2.1 ICE-QM770 Specifications
The ICE-QM770 technical specifications are listed below.
Specifications/Model ICE-QM770
Form Factor
PICMG COM Express R2.0 Type 6 for basic size
(95 mm x 125 mm)
CPU Socket
Socket G2
CPU Supported
2nd and 3rd generation Intel® Core™ i7/i5/i3, Pentium® and
Celeron® processors
Express Chipset Intel® QM77
Memory
Two 204-pin 1600/1333/1066 MHz dual-channel
DDR3/DDR3L (1.35V) SO-DIMMs supported
(system max. 16 GB)
Graphics Engine
Intel® HD Graphics 2000/3000
Supports DirectX 11 OCL 1.1 and OpenGL 3.0
Full MPEG2, VC-1 and AVC decoding
Ethernet
Intel® 82579LM
Supports Intel® AMT 8.0
BIOS UEFI BIOS
Embedded Controller iWDD
Watchdog Timer
Software programmable supports 1~255 sec. system reset
Display
(Signal to Baseboard)
One VGA (up to 2048 x 1536 @ 75Hz) is integrated in the
Intel® QM77
One 18-/24-bit dual-channel LVDS (up to 1920 x 1200 @
60Hz)
Three DDI (up to 2560 x 1600 @ 60Hz)
Expansions
(Signal to Baseboard)
One PCIe x16
Seven PCIe x1
