2.2 COM Express Connector Type
The differences among the Module Types are summarized in Table 2-1.
ƒ Module Type 1 and 10 supports a single connector with two rows of pins
(220 pins total).
ƒ Module Types 2-6 support two connectors with four rows of pins
(440 pins total).
Type Rows PCIe
Lanes
PEG/
SDVO
PCI IDE SATA LAN USB
2.0/3.0
Display
1 AB Up to 6 - - - 4 1 8 / 0 VGA, LVDS
2 AB, CD Up to 22 1/2 32-bit 1 4 1 8 / 0 VGA, LVDS,
PEG/SDVO
3 AB, CD Up to 22 1/2 32-bit - 4 3 8 / 0 VGA, LVDS,
PEG/SDVO
4 AB, CD Up to 32 1/2 - 1 4 1 8 / 0 VGA, LVDS,
PEG/SDVO
5 AB, CD Up to 32 1/2 - - 4 3 8 / 0 VGA, LVDS,
PEG/SDVO
6 AB, CD Up to 24 1/NA - - 4 1 8 / 4 VGA, LVDS,
PEG, 3 x DDI
10 AB Up to 4 -/1 - - 2 1 8 / 0 1 x DDI
Table 2-1: COM Express Connector Type Variations
