Table 3-9: ddi signal descriptions – IEI Integration ICE-DB-T6 User Manual

Page 54

Type 6 Carrier Board Design Guide

Page 44

C43 DDI3_PAIR1-
C46
C47

DDI3_PAIR2+
DDI3_PAIR2-

O PCIe

DDI 3. Transmit Output differential pair 2.

C49
C50

DDI3_PAIR3+
DDI3_PAIR3-

O PCIe

DDI 3. Transmit Output differential pair 3.

D15
D16

DDI1_AUX+
DDI1_AUX-

I 3.3V

CMOS

Selects the function of DDI1_ AUX+ and
DDI1AUX-. This pin shall have a 1M pull-down
to logic ground on the Module. If this input is
floating, the AUX pair is used for the DP AUX+/-
signals. If pulled-high, the AUX pair contains the
CRTLCLK and CTRLDATA signals.

C32
C33

DDI2_AUX+
DDI2_AUX-

I 3.3V

CMOS

Selects the function of DDI2_ AUX+ and
DDI2AUX-. This pin shall have a 1M pull-down
to logic ground on the Module. If this input is
floating, the AUX pair is used for the DP AUX+/-
signals. If pulled-high, the AUX pair contains the
CRTLCLK and CTRLDATA signals.

C36
C37

DDI3_AUX+
DDI3_AUX-

I 3.3V

CMOS

C73

DDI1_CTRLDATA

I/O

DP AUX- function if DDI1_AUX is no connect.
HDMI/DVI I2C CTRLDATA if DDI1_AUX is pulled
high.

D34

DDI2_CTRLDATA

I/O

DP AUX- function if DDI2_AUX is no connect.
HDMI/DVI I2C CTRLDATA if DDI1_AUX is pulled
high.

D38

DDI3_CTRLDATA

I/O

DP AUX- function if DDI3_AUX is no connect.
HDMI/DVI I2C CTRLDATA if DDI1_AUX is pulled
high.

D73

DDI1_CTRLCLK

I/O

DP AUX+ function if DDI1_AUX is no connect.
HDMI/DVI I2C CTRLDATA if DDI1_AUX is pulled
high.

C34

DDI2_CTRLCLK

I/O

DP AUX+ function if DDI2_AUX is no connect.
HDMI/DVI I2C CTRLDATA if DDI1_AUX is pulled
high.

C38

DDI3_CTRLCLK

I/O

DP AUX+ function if DDI3_AUX is no connect.
HDMI/DVI I2C CTRLDATA if DDI1_AUX is pulled
high.

C24 DDI1_HPD

3.3V

CMOS

DDI 1 hot-plug detect

D44 DDI2_HPD

3.3V

CMOS

DDI 2 hot-plug detect

C44 DDI3_HPD

3.3V

CMOS

DDI 3 hot-plug detect

Table 3-9: DDI Signal Descriptions
