Type 6 Carrier Board Design Guide
Page 8
Specifications/Model ICE-DB-T6 Reference Carrier Board
Audio Realtek ALC892 HD Audio codec
GPIO
8-bit GPIO (GPIO from iWDD co-lay SDIO)
Watchdog Timer
Software programmable supports1~255 sec. system reset
Display
1 x 18/24-bit single/dual-channel LVDS
1 x VGA
3 x DisplayPort (two by external connector, one by pin header)
Expansions
(Signal to Baseboard)
One PCIe x16
Five PCIe x1
Two PCIe Mini (with USB)
One LPC
SMBus
One 4-pin wafer
I
2
C
One 4-pin wafer
Front Panel
One connector supports power LED, HDD LED, power button,
reset button, speaker/buzzer
TPM
One 20-pin header
Fan Connector
One 4-pin and one 3-pin CPU module fan connectors
One 3-pin system fan connector by SIO
SD
One SD slot
Other Internal I/O
4 x SATA 3Gb/s port
2 x RS-232 from COM Express (only TX, RX and GND)
2 x RS-232 from SIO
2 x USB 2.0
1 x Audio connector
