Type 6 Carrier Board Design Guide
Page 16
Pin Signal I/F I/O Pin Signal I/F I/O
A93 GPO0 GPIO O B93 VGA_HSYNC VGA O
A94 SPI_CLK SPI O B94 VGA_VSYNC VGA O
A95 SPI_MOSI SPI IO B95 VGA_I2C_CK VGA I/O
A96 PP_TPM TPM I B96 VGA_I2C_DAT VGA I/O
A97 RSVD - - B97 SPI_CS# SPI O
A98 RS1_TX UART O B98 RSVD - -
A99 RS1_RX UART I B99 RSVD - -
A100 GND13 GND - B100 GND25 GND -
A101 RS2_TX UART O B101 FAN_PWMOUT FAN O
A102 RS2_RX UART I B102 FAN_TACHIN FAN I
A103 LID# - I B103 SLEEP# - I
A104 VCC_12V7 PWR - B104 VCC_12V16 PWR -
A105 VCC_12V8 PWR - B105 VCC_12V17 PWR -
A106 VCC_12V9 PWR - B106 VCC_12V18 PWR -
A107 VCC_12V10 PWR - B107 VCC_12V19 PWR -
A108 VCC_12V11 PWR - B108 VCC_12V20 PWR -
A109 VCC_12V12 PWR - B109 VCC_12V21 PWR -
A110 GND14 GND - B110 GND26 GND -
2.5 Connector Pinout Rows C and D
Pin Signal I/F I/O Pin Signal I/F I/O
C1 GND0 GND - D1 GND15 GND -
C2 GND GND - D2 GND GND -
C3 USB_SSRX0- USB 3.0 I D3 USB_SSTX0- USB 3.0 O
C4 USB_SSRX0+ USB 3.0 I D4 USB_SSTX0+ USB 3.0 O
C5 GND GND - D5 GND GND -
C6 USB_SSRX1- USB 3.0 I D6 USB_SSTX1- USB 3.0 O
C7 USB_SSRX1+ USB 3.0 I D7 USB_SSTX1+ USB 3.0 O
C8 GND GND - D8 GND GND -
C9 USB_SSRX2- USB 3.0 I D9 USB_SSTX2- USB 3.0 O
C10 USB_SSRX2+ USB 3.0 I D10 USB_SSTX2+ USB 3.0 O
C11 GND1 GND - D11 GND16 GND -
C12 USB_SSRX3- USB 3.0 I D12 USB_SSTX3- USB 3.0 O
C13 USB_SSRX3+ USB 3.0 I D13 USB_SSTX3+ USB 3.0 O
C14 GND GND - D14 GND GND -
C15 DDI1_PAIR6+ DDI O D15 DDI1_AUX+ DDI O
C16 DDI1_PAIR6- DDI O D16 DDI1_AUX- DDI O
C17 RSVD - - D17 RSVD - -
C18 RSVD - - D18 RSVD - -
C19 PCIE_RX6+ PCIE I D19 PCIE_TX6+ PCIE O
C20 PCIE_RX6- PCIE I D20 PCIE_TX6- PCIE O
C21 GND2 GND - D21 GND17 GND -
C22 RSVD - - D22 RSVD - -
C23 RSVD - - D23 RSVD - -
C24 DDI1_HPD DDI I D24 RSVD - -
C25 DDI1_PAIR4+ DDI O D25 RSVD - -
