Type 6 Carrier Board Design Guide
Page 5
The ICE-CV-D25501/N26001 COM Express module provides the main processing chips
and is connected to a compatible COM Express baseboard. The ICE-CV-D25501/N26001
is equipped with an Intel® Atom™ D2550/N2600 CPU and Intel® NM10 PCH. The COM
Express standard allows the COM Express baseboard to be designed, while leaving the
choice of processor till the later stages of design. The ICE-CV-D25501/N26001 provides a
low power option with the full range of modern I/O options. The ICE-CV-D25501/N26001
embedded module is designed for flexible integration by system developers into
customized platform devices.
1.3.1 ICE-CV-D25501/N26001 Specifications
The ICE-CV-D25501/N26001 technical specifications are listed below.
Specifications/Model ICE-CV-D25501/N26001
Form Factor
PICMG COM Express R2.0 Type 6 for compact size (95 mm x 95 mm)
10 layers
CPU
1.86 GHz Intel® Atom™ D2550 dual-core CPU (2 x 512KB L2 cache)
1.6 GHz Intel® Atom™ N2600 dual-core CPU (2 x 512KB L2 cache)
Chipset Intel® NM10
Memory
D2550: One 1066 MHz DDR3/DDR3L (1.35V) SO-DIMM support (up to
4 GB)
N2600: One 800 MHz DDR3/DDR3L (1.35V) SO-DIMM support (up to
2 GB)
Graphics Engine
D2550: Intel® GMA 3650 with 640 MHz graphics core speed
N2600: Intel® GMA 3600 with 400 MHz graphics core speed
Supports DirectX 9 and Blu-ray 2.0
MPEG2, H.264, VC-1 and 1080p decoding
Display
(Signal to Baseboard)
One VGA (up to 2048 x 1536 @ 75Hz) is integrated in the CPU
One LVDS is integrated in the CPU:
ƒ D2550: 24-bit single-channel LVDS (up to 1440 x 900 @ 60Hz)
ƒ N2600: 18-bit single-channel LVDS (up to 1366 x 768 @ 60Hz)
Two DDI (up to 2560 x 1600 @ 60Hz)
Ethernet Realtek RTL8111E PCIe GbE controller
