IEI Integration ICE-DB-T6 User Manual
Page 28
Type 6 Carrier Board Design Guide
Page 18
Pin
Signal
I/F
I/O
Pin
Signal
I/F
I/O
C74
PEG_RX7+
PEG
I
D74
PEG_TX7+ PEG
O
C75
PEG_RX7- PEG
I
D75
PEG_TX7- PEG
O
C76
GND8
GND
-
D76
GND29 GND
-
C77
RSVD4
-
-
D77
RSVD -
-
C78
PEG_RX8+
PEG
I
D78
PEG_TX8+ PEG
O
C79
PEG_RX8- PEG
I
D79
PEG_TX8- PEG
O
C80
GND10 GND
-
D80
GND23 GND
-
C81
PEG_RX9+
PEG
I
D81
PEG_TX9+ PEG
O
C82
PEG_RX9- PEG
I
D82
PEG_TX9- PEG
O
C83
RSVD5
-
-
D83
RSVD8 -
-
C84
GND6
GND
-
D84
GND30 GND
-
C85
PEG_RX10+
PEG
I
D85
PEG_TX10+ PEG
O
C86
PEG_RX10- PEG
I
D86
PEG_TX10- PEG
O
C87
GND35
GND
-
D87
GND31 GND
-
C88
PEG_RX11+
PEG
I
D88
PEG_TX11+ PEG
O
C89
PEG_RX11- PEG
I
D89
PEG_TX11- PEG
O
C90
GND27 GND
-
D90
GND24 GND
-
C91
PEG_RX12+
PEG
I
D91
PEG_TX12+ PEG
O
C92
PEG_RX12- PEG
I
D92
PEG_TX12- PEG
O
C93
GND11
GND
-
D93
GND32 GND
-
C94
PEG_RX13+
PEG
I
D94
PEG_TX13+
PEG
O
C95
PEG_RX13- PEG
I
D95
PEG_TX13- PEG
O
C96
GND12
GND
-
D96
GND33 GND
-
C97
RSVD6
-
-
D97
PEG_ENABLE#
PEG
I
C98
PEG_RX14+
PEG
I
D98
PEG_TX14+
PEG
O
C99
PEG_RX14- PEG
I
D99
PEG_TX14- PEG
O
C100
GND13 GND
-
D100
GND25 GND
-
C101
PEG_RX15+
PEG
I
D101
PEG_TX15+
PEG
O
C102
PEG_RX15- PEG
I
D102
PEG_TX15- PEG
O
C103
GND
GND
-
D103
GND34
GND
-
C104
VCC_12V1 PWR
-
D104
VCC_12V7 PWR
-
C105
VCC_12V2 PWR
-
D105
VCC_12V8 PWR
-
C106
VCC_12V3 PWR
-
D106
VCC_12V9 PWR
-
C107
VCC_12V4 PWR
-
D107
VCC_12V10 PWR
-
C108
VCC_12V5 PWR
-
D108
VCC_12V11 PWR
-
C109
VCC_12V6 PWR
-
D109
VCC_12V12 PWR
-
C110
GND14 GND
-
D110
GND26 GND
-
