Conquest Versions
2
Conquest M2 (SBAE30) and Conquest Supported Features
Feature
Conquest
M2
St
an
d
a
rd
Adv
an
ced
Pro
Pro
Exer
ciser
Low Speed (1.5 Mb/s) and Full Speed (12 Mb/s)
+
+
+
+
High Speed (480 Mb/s)
+
+
+
+
Trace Memory Size
128 MB 128 MB 394 MB 394 MB
Upload to Host via USB 2.0 or LAN
+
+
+
+
Global & Raw Bit View
+
+
+
+
View Hex, Decimal or Binary
+
+
+
+
Search on Errors
+
+
+
+
Search within Data Payload
+
+
+
+
Export Text / ASCII / Binary
+
+
+
+
Snapshot Capture
+
+
+
+
Data Report
+
+
+
+
Upper-level USB Device Class Decodes
+
+
+
+
User-defined Decodes
+
+
+
+
Single-level Event Triggering (Easy mode)
+
+
+
+
Trigger on Protocol Errors
+
+
+
+
Trigger on Setup / In / Out / Data / Ping
+
+
+
+
Statistical Reports
+
+
+
Multi-level Event Triggering (Advanced mode)
+
+
+
Trigger on Split Setup Transaction
+
+
+
Trigger on Split Bulk In/Out Transaction
+
+
+
Trigger on Split Interrupt In/Out Transaction
+
+
+
Trigger on Split Isoch In/Out Transaction
+
+
+
Filter In / Out specific Address / Endpoints
+
+
+
Trigger on Data Pattern and Length
+
+
Trigger on Vbus & Operating Current
+
+
Event Counters
+
+
Event Timers
+
+
Auto Run (multiple trace capture)
+
+
Auto detect Speed
+
+
Slow-clock Capability
+
+
Performance Analyzer (Easy \ Advanced Option)
+
+
OTG Analysis
+
+
Timing Analysis Display
+
+
DC Compliance measurement
+
+
Find Device (View Scan descriptor)
+
Exerciser Graphical User Interface (GUI)
+
Traffic Generation / Host emulation
+
Simultaneous Transmit and Record
+
Device emulation
+
OTG Device Emulation
+
