User Manual PXA125
Installation 2-39
Figure 2-24 – Setup Complete
The
ArbDetector
The ArbDetector detects all arbitrary waveform generators that are
plugged into the PXI chassis and lets you review instrument identity,
serial number, installed options etc. You may also use the device
detector to fine-tune your controller type, chassis size and slot
location.
Before you can start using the PXA125, you must make sure that the
ArbDetector has been invoked. Look at your right lower end of your
screen and identify the Startup bar. The ArbDetector icon looks as
shown in Figure 2-25.
The ArbDetector is automatically invoked from the startup menu after
you power on your computer. If, for any reason you cannot find the
ArbDetector icon, you’ll have to invoke it manually. From the Start
button select Programs, then Startup and finally the ArbDetector
command. The detector will be invoked and the icon placed at the
startup tray.
Figure 2-25. The ArbDetector Icon at the Startup Tray
