User Manual PXA125
Programming Reference 4-60
INSTrument
Subsystem A dual channel arbitrary waveform generator is considered as two
logical instruments. The INSTrument subsystem provides a
mechanism to identify and select instrument channels. Factory
defaults after *RST are shown in bold typeface. Parameter low and
high limits are given where applicable.
Keyword Parameter Form Default,Low Limit,High
Limit
:INSTrument (?) {1|2} 1
:COUPle (?) {OFF|ON|0|1} OFF
:MODE (?) (MASTer|SLAVe) MASTer
:PHASe (?) 0,0,n
:SET {0|1|2} 0,0,2
INSTrument:COUPle{OFF|ON|0|1}
Purpose
This command will enable daisy-chained instruments to operate in multi-instrument synchronization mode.
•
ON or 1 will set the couple mode on
•
OFF or 0 will set the couple mode off
Parameter type
Discrete
INSTrument:COUPle?
Response and default
The PXA125 will return 0, or 1 depending on the present instrument couple setting. Default value is 0.
INSTrument:COUPle:MODE{MASTer|SLAVe}
Purpose
This command will select master and slave instruments in multi-instrument synchronization mode. Note that
only one instrument in a chain may be set as master. All other instruments must be set as slaves.
•
MASTer will set the master instrument
•
SLAVe will set the slave instrument
Parameter type
Discrete
INSTrument:COUPle:MODE?
Response and default
The PXA125 will return MAST, or SLAV depending on the present instrument couple setting. Default value is
MAST.
