User Manual PXA125
Portrayal 1-3
OUTPUT
10M REF IN
SINE OUT
SYNC OUT
TRIG IN
PXA125
TTL
1Vp-p
GENERATOR
WAVEFORM
125MS/s
LeCroy
Figure 1-1, PXA125
ArbConnection
Feature
Highlights •
Three powerful tools in one software package: Instrument control
panel, Waveform composer and FM signal composer
•
Detailed virtual front panels control all PXA125 functions and
modes
•
Wave composer generates, edits and downloads complex
waveforms
•
FM wave composer generates and downloads complex
modulating signals
•
Automatic detection of active instruments
•
Equation editor generates waveforms from equations
•
SCPI command and response editor simulates ATE operation
