User Manual PXA125
Specifications A-99
Flatness -3dB at 100 MHz
Total Harmonic Distortion 0.3% to 100 KHz
-55dBc to 1 MHz
Harmonics and non-related spurious -45dBc to 10 MHz
-35dBc to 100 MHz
INPUTS
TRIG Input
Connector Front panel BNC
Impedance 10 K Ω , ± 5%
Threshold LevelTTL
Damage Level ± 10 V
Min Pulse Width 20 ns
Slope Positive or negative going edge.
10 MHz Reference Input
Connector Front panel SMB
Impedance 10 K Ω , ± 5%
Threshold LevelTTL
Damage Level ± 10 V
Duty Cycle 50%, ± 5%
GENERAL
Power Requirements 10W maximum
Current Consumption +5 V - 30 mA
+12 V - 200 mA
