User Manual PXA125

Programming Reference 4-30

Table 4-1. Model PXA125 SCPI Commands List Summary (continued)

Keyword

Parameter Form (Default in Bold)

Notes

:SEQuence

[:DATA]

:ADVance

AUTOmatic | STEP | SINGle | MIXed

:SOURce

EXTernal | INTernal |TTLTrig 0-7 | STAR

:DEFine

(1;1;4096),(1;1;4096),(1;1;128K),(0,0,1)

Step, segment, repeat,
advance mode

:DELete

:ALL

:INITiate

[:IMMediately]

:CONTinuous

ON | OFF

:TRIGger

:BURSt

[:STATe]

OFF | ON

:COUNt

(1;1;1E6)

:SOURce

:ADVance

EXTernal | INTernal | TTLTrig 0-7 | STAR

:GATE

[:STATe]

OFF | ON

:SLOPe

POSitive | NEGative

:TIMer

(1e3;100e-3;5e6)

In Hz units

:STAR

[:STATe]

OFF | ON

:PHASe

(0;0;n) where “n” is the size of the active segment

4 points increments

:ARM

[:STATe]

OFF | ON

:SLOPe

[:STARt]

POSitive | NEGative

:BREakpoint

:POSition

(0;0;999999)

4 points increments

:RESet

:SYSTem

:ERRor?

Query only

:VERSion?

Query only, 1999.0

:IDENtification

Query only
