Dimension, mass and maximum speed by stroke – IAI America ISPDACR-ESD User Manual
Page 115

107
13. Appendix
13.1.18 ISDACR-W-750,
ISPDACR-W-750
Cable joint
connector *1
Home
At least 100 or more
Stroke
Weight (kg)
4-M8, depth 24
m-M8, depth 25
Dimension, Mass and Maximum Speed by Stroke
SE: Stroke end
ME: Mechanical end
Reference surface
Detail view of A
4-
8H7, reamed, depth 10
L (stroke + 479)
2-
8H7, reamed, depth 10
2-
8H7, reamed, depth 10
Detail view of P
Outer diameter of applicable tube:
12 (inner diameter 8)
Effective stroke
4-M6, depth 24
* The appearance diameters are the same if
equipped with brake.
The weight increases in 0.5kg
