Section 4: Input/ Output

2/2013

74

51303 Rev. 1

5.1.2. EM-U432 THERMAL PRINTER SETTINGS,

CONTINUED

SETTINGS FOR DIP SWITCH DSW2

SW
NO.

FUNCTION

ON

OFF

1

EU-T432

– 79.5mm paper-width model; 576

dots, 3.15”

Switch 1 –
On

Switch 2 –
OFF

2
3

Print Density Selection .

See

Print Density Selection

chart below.

4
5

Operation Mode Selection

See

Operation Mode Selection

chart below.

6 Factory

Use

7

I/F Pin 6 reset signal – 1

Enabled

Disabled

8

I/F Pin 6 reset signal – 2

Enabled

Disabled

LEVEL

PRINT DENSITY SELECTION

SWITCH NUMBER

3

4

1 Slightly

Light

ON

ON

2

Normal

OFF

OFF

3

Slightly Dark

ON

OFF

4

Dark

OFF

ON

OPERATION MODE SELECTION

SWITCH NUMBER

5

Hexadecimal Dump

ON

Normal

OFF

NOTES:

Changes in DIP Switch settings (excluding switches

2-7

and

2-8

Interface Reset

Signals

) are recognized only when the printer power is turned on, or when the

printer is reset by using the Interface.

Turning on the DIP Switches

2-7

and

2-8

while the printer power is turned on, the

printer may be reset, depending on the signal state.

DIP Switches should not ever be changed while the printer power is on.
