Method 1 – pre-configured output – Fairbanks FB2550 DAT SERIES DRIVER ACCESS TERMINAL User Manual
Page 52
Section 3: Configuration Menu
2/2013
52
51303 Rev. 1
4.4.3. METHOD 1 – PRE-CONFIGURED OUTPUT
Follow these steps to configure an output data string on the FB2550 DAT,
completed in the Configuration Menu.
1. Using an external keyboard, press
ALT +
HOME
.
2. Select
LOGIN
.
3. Enter the Supervisor Password.
4. Select the
CONFIGURATION MENU
and press
PAGE FORWARD
once.
5. Select
CONFIGURE OUTPUTS
.
6. Touch the screen to select
CONFIGURE
COM
X,
where
X
is the desired COM port
location to configure the output data string.
NOTE:
In the following images,
CONFIGURE COM1
was selected.
