Appendix II: Data Output
2/2013 148 51303 Rev. 1
B. CONFIGURE OUTPUT, CONTINUED
TOLEDO DATA FORMAT
NOTES:
1. Characters denoted by G and T are Characters 0-9.
2. Leading zeroes are not suppressed.
3.
Gross Weight data = G
Tare Weight data = T
Status Code (Word) A
Increment Size
Bit # Count By 1 Count by 2 Count by 5
3 1 0 1
4 0 1 1
5 Always Logic 1
6 Always Logic 0
7 Parity Bit
Bit # X00 X0 X X.X X.XX X.XXX X.XXXX X.XXXXX
0 0 1 0 1 0 1 0 1
1 0 0 1 1 0 0 1 1
2 0 0 0 0 1 1 1 1
