Appendix II: Data Output

2/2013

149

51303 Rev. 1

B. CONFIGURE OUTPUT, CONTINUED

TOLEDO DATA FORMAT

Status Code (Word) B









Status Code (Word) C










Bit #

Description

0

Gross = 0

Net = 1

1

Positive = 0

Negative = 1

2

In Range = 0

Overcapacity = 1

3

No Motion = 0

Motion = 1

4

Lb = 0

Kg = 1

5

Always Logic = 0

6

Normal = 0

Power Up = 1

7

Parity Bit

Bit #

Description

0

Always Logic = 0

1

Always Logic = 0

2

Always Logic = 0

3

Normal = 0

Print Switched Pushed = 1

4

Always Logic = 0

5

Always Logic = 1

6

Normal = 0

Keyboard Tare = 1

7

Parity Bit
