Section 3: Configuration Menu
2/2013 64 51303 Rev. 1
4.4.4. METHOD 2, CONTINUED
30. Press PAGE FORWARD once again.
– This page configures the Mode: token
for the output data string.
– Each item configured will indicate the
character(s) programmed in the output
data string.
– The REMOTE COMMANDS
configuration establishes if a carriage
return is required when sending a remote command, such as a Zero
Command
.
– If the check box is selected, the remote Zero Command is Z.
Otherwise it would be a “Z” only.
31. Press the SAVE CHANGES button when any changes are made.; Otherwise,
the changes will be lost.
 Selecting BACK: CONFIGURE COM1 will return the user to the Configure
COM1 Menu.
 Touch RETURN TO WEIGHING TO TEST and verify the output is
producing the desired results.
