Appendix I: Fieldbus Interface Reference Data

2/2013

143

51303 Rev. 1

E. STATUS/COMMAND WORD BIT USAGE, CONTINUED

KG WEIGHT UNITS

WORD 0

BIT 9

Command: Switch scale to kg units.
Status:

Scale is indicating in kg units.

TON WEIGHT UNITS

WORD 0

BIT 10

Command: Switch scale to ton units.
Status:

Scale is indicating in ton units.

TONNE WEIGHT UNITS

WORD 0

BIT 11

Command: Switch scale to tonne units.
Status:

Scale is indicating in tonne units.

DECIMAL LOCATION

WORD 1

BITS 0,1,2

Command: Used in integer to float weight conversions.
Status:

Indicates location of decimal point in weight data.

LOAD TARE

WORD 1

BIT 3

Command: Load tare from tare memory address.
Status:

Switches to 1 after command is executed and returns to 0 when
command is cleared.

AUTO TARE

WORD 1

BIT 4

Command: Take current scale gross weight as tare value.
Status:

Switches to 1 after command is executed and returns to 0 when
command is cleared.

LOAD

SETPOINT

1

WORD

1 BIT

5

Command: Load setpoint 1 for this scale.
Status:

Switches to 1 when command is executed returns to zero when
command is cleared.
