Network setup procedure, Network terminal name – Fairbanks FB2550 DAT SERIES DRIVER ACCESS TERMINAL User Manual
Page 128

Section 7: Network Application Configuration
2/2013
128
51303 Rev. 1
8.3. NETWORK SETUP PROCEDURE
8.3.1. NETWORK
TERMINAL
NAME
Follow these steps to setup the Network Name.
1. From the Weigh Screen, select
ALT +
MENU
.
2. Select
LOGIN
and enter the Service
Password
.
3. Select the
CONFIGURATION
MENU
.
4. Page Forward twice.
5. Select
NETWORK
PARAMETERS
.
6. Input a
NETWORK
NAME
from the list
below.
– TERMINAL1
– TERMINAL4
– TERMINAL2
– TERMINAL5
– TERMINAL3
IMPORTANT NOTE:
USE ONLY THE NETWORK NAMES LISTED ABOVE,
and be certain that they are not duplicated.
7. Press the
SAVE CHANGES
button when any changes are made or they will
be lost.
8. Return to the Weigh Screen.
9.
Shut down and restart the FB2550 DAT.
All setup changes will apply after the Instrument reboot.
IMPORTANT NOTE:
Reboot the FB2550 DAT correctly, or program files can
become corrupted.
See
Section 9.3. Proper Shutdown Procedure.
